Aluminum Radiator Shroud Fan Relay for 1953 1954 1955 1956 F100 F250 F350 Pickup Truck Chevy V8 L6 4 Row Core Radiators Shroud Fan Relay

Fitment： For Ford F-100/ F-250/ F-350 3.5L l6 GAS 1953 For Ford F-100/ F-250/ F-350 3.6L l6 GAS 1954 1955 1956 For Ford F-100/ F-250/ F-350 3.9L V8 GAS 1953 1954 1955 For Ford F-100/ F-250/ F-350 4.2L V8 GAS 1955 For Ford F-100/ F-250/ F-350 4.4L V8 GAS 1955-1956 Part Number: 8356,CC8356,MC8356,DPI8356 AE8356 EC8356 KKS8356,SBR8356 SPTCU8356 Q8356 DPI8356 RA8356 RK8356 Package Includes: 1 X 4-Row AA5052 Aluminum Radiator 1 X CNC Machined Radiator Cap 1 X AA5052 Aluminum Shroud 1 X 16" Fans (Includes mounting kits) 1 X Thermostat Relay Kit 16" Fan: Voltage: DC 12 Volts Maximum Fan CFM: 2150 cfm Wattage: 120 Wattage Thickness (in): 2.500" Number of Blades: 10 S-Type blades Maximum Fan RPM: 2,250 rpm Amp Draw: 10 amps Radiator Details: Rows：4 Rows Features: 100% Leak Tested,Downflow Radiator, Durability Tested, No Drilling or Modifications Needed for Installation Mounting Style: Screw-OnFitment Type: Performance/Custom Placement on Vehicle: Engine Compartment Thermostat Kit Installation: Universal fit for any automotive vehicle and electric fan. Activates by grounding electric fans at preset temperature. 180'F turn-on temperature, 165'F turn-off temperature. Probe typically threads into radiator, water outlet or manifold. RED + connect directly to battery. WHITE wire to ignition switch power source. BLACK goes to thermos switch. BLUE wire goes to the Fans.

• Radiator : Core Size : 20.28" H x 22.76" W x 2.44" T; Overall Size: 25.89" H x 26.22" W x 5.85" T ; Inlet/Outlet: 1.38"/1.78" ; Transmission Oilcooler: φ26*200*G1/4(Z)
• Includes CNC machined filler neck and cap,OEM Style Brass Petcock Drain
• High-quality material: Transmission Oil Cooler is constructed of high quality AA5052 aircraft grade aluminum construction to ensure an extremely long lasting operate life. The core of the Transmission Oil Cooler is welded in vacuum brazing furnace, no epoxy.
• Easy To Install: Light weight direct bolt-on replacement, stronger & higher capacity for coolant
• Fitment： For Ford F-100 ；F-250 ；F-350 3.5L l6 GAS 1953 | For Ford F-100 ；F-250 ；F-350 3.6L l6 GAS 1954 1955 1956 | For Ford F-100 ；F-250 ；F-350 3.9L V8 GAS 1953 1954 1955 | For Ford F-100 ；F-250 ；F-350 4.2L V8 GAS 1955 | For Ford F-100 ；F-250 ；F-350 4.4L V8 GAS 1955-1956
